The revolutionary Pitbull® Clamp remains the lowest profile, highest holding force clamp in the industry today. High vertical and horizontal clamping forces are generated, considering the size of the Pitbull® Clamps.
It uses a standard cap screw and an oil resistant O-ring. The Pitbull® Clamp is available in 5 sizes and several styles, a tool steel knife edge for aggressive stock removal, a tool steel blunt edge for general purpose, a brass version to help prevent marring the workpiece and a machinable version.
Also available is the Pitbull® Wear Plate. This shim provides a hard barrier between Pitbull® Clamp and fixture, preventing distortion of back wall when using aluminum or mild steel fixtures. Simple solution to keep fixtures light, maintain full clamp travel and holding forces at max pressure. Refurbish old fixtures or add to existing aluminum fixtures to maximize machining capabilities.
Metric
| Part No. | Description | A | B | Clamp Width C |
D* | E | SHCS Screw Size |
Max Torque (N.m.) |
Holding Force (N.) |
Total Throw |
No. Clamps Per Package |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 56000 | Tool Steel, Knife Edge | 3.81 | 3.55 | 9.52 | 1.90 | 6.60 | M2.5 | 1.8 | 2800 | .190 | 8 |
| 56010 | Tool Steel, Blunt Edge | 3.81 | 3.55 | 9.52 | 1.90 | 6.60 | M2.5 | 1.8 | 2800 | .190 | 8 |
| 56015 | Brass, Blunt Edge | 3.81 | 3.55 | 9.52 | 1.90 | 5.59 | M2.5 | .56 | 875 | .190 | 8 |
| 56020 | Tool Steel, Knife Edge | 5.08 | 4.75 | 12.70 | 2.54 | 9.90 | M4 | 5.6 | 6600 | .406 | 8 |
| 56030 | Tool Steel, Blunt Edge | 5.08 | 4.75 | 12.70 | 2.54 | 9.90 | M4 | 5.6 | 6600 | .406 | 8 |
| 56040 | Brass, Blunt Edge | 5.08 | 4.75 | 12.70 | 2.54 | 8.64 | M4 | 2.8 | 1750 | .406 | 8 |
| 56050 | Tool Steel, Knife Edge | 7.62 | 7.11 | 19.05 | 3.81 | 14.48 | M6 | 22.5 | 16000 | .610 | 6 |
| 56060 | Tool Steel, Blunt Edge | 7.62 | 7.11 | 19.05 | 3.81 | 14.48 | M6 | 22.5 | 16000 | .610 | 6 |
| 56065 | Brass, Blunt Edge | 7.62 | 7.11 | 19.05 | 3.81 | 11.18 | M6 | 5.6 | 4200 | .610 | 6 |
| 56070 | Tool Steel, Knife Edge | 10.16 | 11.43 | 25.4 | 6.35 | 18.03 | M10 | 40.6 | 26000 | 1.270 | 4 |
| 56075 | Tool Steel, Blunt Edge | 10.16 | 11.43 | 25.4 | 6.35 | 18.03 | M10 | 40.6 | 26000 | 1.270 | 4 |
| 56080 | Tool Steel, Knife Edge | 15.24 | 16.26 | 38.1 | 9.52 | 19.56 | M12 | 145.0 | 50000 | 1.900 | 2 |
| 56085 | Tool Steel, Blunt Edge | 15.24 | 16.26 | 38.1 | 9.52 | 19.56 | M12 | 145.0 | 50000 | 1.900 | 2 |
